by David Rutten (Last updated: Tuesday, September 1, 2026)

By the end of this document, you should have a sufficient grip on what it takes to port components from a Grasshopper 1.0 GHA plugin to a Grasshopper 2.0 RHP plugin. It will discuss the major and minor differences in both the over-arching architecture and specific namespace and type names.

Prerequisites

This document presumes you have experience with developing components for Grasshopper 1.0 in C#.

Introduction

From a bird’s eye view, component development in GH1 and GH2 are two almost identical processes. On both platforms one must create a distinct class per component, assign it a unique ID, give it a name and description, a tab and panel location, specify the input and output parameters and finally implement the function which computes the outputs from the inputs. However, the specifics differ to lesser and greater degrees, occasionally in unexpected ways.

Here’s a list of conceptually significant differences in no particular order:

• Many types in Grasshopper 2 are immutable, which often necessitates a different way of doing things.
• Component IDs are type attributes rather than class properties.
• The solver is inherently multi-threaded, which makes it much harder to store values or states in class-level variables.
• The solver is inherently cancellable.
• New native data types such as Functions, Fields, Gradients, BigIntegers, and Angles often require a rethinking of how components can/should work.
• Type functionality is provided via Assistants rather than an IGH_Goo interface.
• The existence of meta data complicates operations which shuffle or restructure lists of values.
• Vector based icons are now supported and recommended.
• Documentation content is created using authoring tools provided by Grasshopper 2.

Plugin Assembly

For a .NET assembly to be considered a valid Grasshopper Plugin it should use the .RHP extension and it must contain a public class with an empty constructor which inherits from the Grasshopper2.Framework.Plugin type, which is the equivalent of the GH_AssemblyInfo type in GH1.

Unlike GH_AssemblyInfo however, plugin identity and authorship are no longer specified in code. Instead they are read from assembly attributes, so that a single *.rhp file can act as both a Rhino plugin and a Grasshopper plugin using a single set of metadata. The table below lists which attribute feeds which plugin property:

Property	Assembly attribute	Notes
Id	[assembly: Guid]	The same id Rhino uses to identify the plugin.
Name	[assembly: AssemblyTitle]	The <AssemblyTitle> project property. Falls back to the file name.
Info	[assembly: AssemblyDescription]	The <Description> project property.
Version	[assembly: AssemblyFileVersion]	The <FileVersion> project property. The same version Rhino reports for the plugin.
Author	[assembly: PlugInDescription(DescriptionType.Organization, ...)]	Falls back to the AssemblyCompany attribute.
Contact	[assembly: PlugInDescription(DescriptionType.Email, ...)]
Website	[assembly: PlugInDescription(DescriptionType.WebSite, ...)]
Copyright	[assembly: AssemblyCopyright]	The <Copyright> project property. A {now} placeholder in the text is expanded to the current year when the plugin loads.

In an SDK-style project the standard .NET attributes are generated from properties in the *.csproj file, while the Guid and the Rhino PlugInDescription attributes are typed directly into a source file:

That leaves very little for the plugin class itself to do. The icon and licence details are the only pieces of information which still have to be supplied from code:

All the properties in the table remain virtual, so whenever a value has to be computed at runtime rather than baked into the assembly metadata, simply override the property in question and the corresponding attribute will be ignored.

Loading Plugins

Since GH2 plugins are also Rhino plugins, they are distributed and installed through the regular Rhino PackageManager command. Grasshopper scans the Rhino plugin install folders for *.rhp files, works out which of them contain Grasshopper 2 content, and remembers the verdict per file so subsequent startups stay fast.

Plugins which are still being developed or debugged can be installed directly from disk; they can be registered by file path from the plugin viewer, which opens with the GH2Plugins command in Rhino. The viewer lists every plugin Grasshopper knows about — loaded, failed, or deliberately skipped — along with the components each one provides, making it the first place to look when a plugin does not show up on the canvas.

Finally, a note on runtimes. Rhino can start in either .NET Framework or .NET Core mode, and a plugin installed as a package may ship a separate build for each, placed in subfolders named after their target framework monikers (net48, net8.0, and so on). Grasshopper resolves the copy which best suits the running session at load time, so cross-platform plugins should ship both variants whenever they can.

Components

The basic layout for a component class in GH2 closely tracks with what you’re probably used to, with just a few minor administrative changes. As mentioned above, the component identifier is not a property of the class, but rather an attribute of the IoIdAttribute type, provided by the GrasshopperIO.dll assembly. The Nomen type bundles together the values which describe and position an object within the Grasshopper user interface; it is used everywhere objects need a name, a descriptive info text, and tab+panel locations. The Nomen provided in the constructor provides not just the name, info, tab and panel data, but also the Slot (placing the component in a specific slot within the panel) and the Rank (specifying the importance of the component, affecting sort order within the UI).

Due to the nature of the (de)serialisation api in GH2, a second constructor is required which takes a single IReader argument and calls the base class constructor. This is an unfortunate complication caused by the fact that the GH2 deserialisation logic must work for immutable types, requiring deserialisation to be implemented via constructors.

For comparison’s sake, below is an equivalent example component class as it would be written in GH1. Note that the three properties at the bottom have all disappeared in the GH2 code. The Exposure property is now part of the Nomen type, the ComponentGuid has morphed into an attribute, and the Icon property can be omitted altogether, provided that an icon file with the same name as the component class is available as an embedded resource in the plugin assembly.

Component Parameters

Adding inputs and outputs to a component is, again, conceptually very similar in GH1 and GH2. Two methods need to be overridden, and the provided parameter manager is used to add new parameters in the order in which they appear on the component from top to bottom. Consider the following code snippet which was taken from the GH1 Circle component:

Apart from some name changes, the equivalent code in the GH2 Circle Radius component is nearly identical:

The minor differences worth noting include:

• The Item access is implied and need not be specified in GH2. Only inputs and outputs which operate on twigs or trees need to have their Access property set.
• Default values are no longer part of the AddX() methods, but are instead assigned using the Set(...) method on the returned parameter. It is recommended that all non-optional inputs have default values assigned, so that a component works “out of the box” when dragged onto the canvas.
• Inputs and outputs in GH2 ought to have two-letter user names instead of single letter names. This provides a much richer layer of information to the user.
• The optionality of inputs is slightly more advanced in GH2. Instead of a single boolean value marking an input as Optional, GH2 provides a three state enumeration. Inputs by default have Requirement.MustExist, but have two different optional states called Requirement.MayBeNull and Requirement.MayBeMissing. The component Process() function will not run if the input values are not compliant with the set requirements.

Major differences worth noting include:

• GH2 provides a larger set of native types and parameters, which should be used whenever they make sense. More on this below.
• GH2 provides some additional options on some parameters (such as Indexing on Integer parameters, or Type Filters on Numeric parameters) which ought to be set when appropriate.
• GH2 parameters all have a Preset system, although this is used almost exclusively on Integer parameters to represent enumerations.

New Parameter Types

The table below lists some new parameter types and when to use them.

Types	Usage
Field	Fields (although technically not new) replace number or vector inputs when the component operates on an unambiguous location in space. Using the example code above, the circle radius input is no longer a number in GH2, but a field, since the circle centre point provides a clear location for the sampling of the field.
Angle	The angle type replaces Number whenever that number was used to represent an angle. Angles can be represented in Degrees, Radians, Turns, Grades and Spreads, allowing the user to specify them in whatever unit makes the most sense to them.
Numeric	The Numeric parameter supports all native number types in GH2, including System.Double, System.Int32, System.Numerics.BigInteger, System.Numerics.Complex and Grasshopper2.Types.Numeric.Angle. Exactly which of these is allowed in any specific numeric parameter depends on the filter set by the developer.
Function	Functions sometimes replace numbers if the context allows for that.
Gradient	Gradients sometimes replace colours if the context allows for that.
Random	The Random parameter replaces an integer seed input. GH2 supports a variety of random engines, and the RandomEngine type combines the choice of engine plus seed value into one.
Surface	The Surface parameter in GH2 acts as a unified container for all surface types; Rhino.Geometry.Surface, Rhino.Geometry.Brep, Rhino.Geometry.SubD, Rhino.Geometry.Sphere, Rhino.Geometry.Box, and Grasshopper2.Types.Shapes.Tube for example.
Point 2	A two-dimensional point, typically used to represent (uv) coordinates and sometimes statistical samples.
Triangle	It’s just for triangle primitives bro.
Polyline	Polylines are their own type now bro.
Sphere	Spheres are available now bro.
Tube	Tubes are a GH2 native type able to represent cones, cylinders, and tubes, both with and without wall thickness.
Deform	Deformations, i.e. SpaceMorphs are available as native types in GH2.
Region	A region is a set of closed co-planar curves without self-intersections. Use this instead of regular curves when dealing with planar inside-outside logic.
Curve Locus	Loci replace curve parameters in GH2. Do not use numbers to identify points on curves, use a curve locus.
Surface Locus	Loci replace surface uv-parameters in GH2. Do not use numbers to identify points on surfaces, use a surface locus.

The use of enumerations as inputs is fairly common in GH2 and has been implemented via the Integer parameter along with presets. The inputs.AddEnum(...) method provides a shorthand for adding an integer parameter with registered presets. For an Enum to be used in this way its underlying type must be System.Int32, and ideally it provides detailed descriptions and a unique colour for each value. Below is the partial code for the DistanceMetric enumeration, which for each item provides a UiInfo() and UiTint() attribute, and for some items even a UiName() attribute to override the name as shown in the GH2 UI.

When properly set up this way, presets can be chosen using the Preset Picker object:

Also note that GH2 supports Quaternions alongside old-fashioned 4x4 transform matrices. HOW-EVER, quaternions are encoded inside Transform matrices so whenever your component consumes transforms, be sure to always check whether they actually represent quaternions using the IsQuaternion() and ToQuaternion() extension methods on Rhino.Geometry.Transform.

Component Processing

The key difference to bear in mind when writing processing code for GH2 components is that component iterations by default run on separate threads. Because of this, the code inside the Process(IDataAccess access) method must be thread-safe. If this is impossible, the threading state of the component must be downgraded from the default ThreadingState.MultiThreaded to ThreadingState.SingleThreaded via the Component.Threading property.

Furthermore, if the processing code is liable to take longer than a few milliseconds, the component should pay attention to cancellation requests by occasionally calling access.Solution.Token.ThrowIfCancellationRequested().

Expiry and New Solutions

In GH1, a single call to ExpireSolution(true) both marked a component as stale and scheduled a recompute. GH2 splits this into two separate steps: Expire() marks an object and everything downstream of it as expired (and request-cancels any solution currently running in the document), while Document.Solution.Start() actually begins a new solution. A typical menu or event handler therefore looks like this:

For objects which generate rapid-fire expiration waves (such as mouse-moves on sliders or key-presses in text fields) call Document.Solution.DelayedExpire(obj) instead. This method batches up expired objects and is smart about when to interrupt: if no solution is running it expires and restarts immediately. However, if a solution is already running, it is allowed a brief interval in which to complete, before it is cancelled anyway.

Every solution is identified by a SolutionId, issued app-wide in ascending order. This id allows code to find out whether a specific solution has since been cancelled, and to determine which of two solutions is newer. Note that there is at present no way to check whether a solution is still running or has completed.

A Random Walk Example

Let’s start with a relatively simple example of a component which doesn’t operate on lists or trees, and doesn’t need to deal with meta data. This example will introduce getting and setting individual values, dealing with fields and random engines, and how to implement cancellation. The component contains three inputs; a Sphere, a Field and a RandomEngine, and outputs a single Polyline representing a random walk from the centre of the sphere to the boundary. First, the code:

1. Getting values in GH2 components uses the out rather than the ref keyword, so is somewhat more economical. Null checks aren’t required if the input Requirement is set to MustExist. Validity checks may be necessary, but we’ll focus on those in a later example.
2. This component has a pseudo-random aspect, which means it requires a RandomEngine as an input. The RandomEngine.CreateInstance() method is used on an engine value to create a new random number generator of the correct type with the specified seed. Also note that GH2 provides a lot of useful extension methods via the Grasshopper2.Extensions namespace, so when that is added to the using block of your C# file you’ll get access to methods like Random.NextUnitVector3D().
3. Since the while loop in this component can potentially run for a very long time, it is important that cancellation is checked often. The Solution object passed to the component via the IDataAccess argument has a token which can be used for this. In GH2, every time a new solution starts, any currently running solution in that document is automatically cancelled.
4. Assignment of output values works exactly the same in GH2 as in GH1, at least when meta data or twigs or trees are not involved.

Working with Twigs and Curves

Grasshopper 2 takes a different approach to curve values. There are still dedicated parameters for specific curve types such as Line, Circle, Arc, Rectangle, etc., but the Curve parameter does not convert all curve-like values into Rhino.Geometry.Curve compliant types. Instead, the Curve parameter stores all curve values as-is, and only makes sure that each value is associated with a centrally registered CurveAssistant. This new approach has two benefits. First, it allows values to be stored without converting them to a different type. Second, it allows plug-ins to add their own curve-like types and trust that all existing components that operate on curves will be able to handle these new values. The drawback to this approach is that dealing with curves can be somewhat or significantly more complicated for component developers, depending on what curve operations a component needs to perform.

In the following example, we’ll create a component which sorts curves based on whether their end-points both lie within a box, both outside of that box, or one-within-and-one-without. This example will discuss how to deal with twigs, curve assistants, and how to correctly persist meta data from input curves to output curves. The default meta-data-copying-mechanism in components will fail if the order of input and output values is not consistent.

This component must operate on entire twigs instead of individual values, for if each curve was treated individually, a null value would be automatically inserted into the two outputs where the curve did not end up. If this is desired behaviour, then by all means operate on single values, but in this case we want the outputs to contain no nulls.

As such, the first input and all three outputs need to be marked with Access.Twig when adding these parameters:

“Twigs” in GH2 are equivalent to “Branches” in GH1. The word “branch” was not only topologically slightly incorrect, it also did not consist of four letters. GH2 uses exclusively 4-letter words to refer to the various types involved in data trees; tree, twig, item, path, pear, site, rule, null, and meta.

The Process() method for this component has to take care to correctly deal with null items in the twig, and to maintain the pairing of items with their original meta data. First consider the implementation, then we’ll discuss the details:

1. When the type constraint of an input is known, for example when the input is an Integer Parameter, then the generic access.GetTwig<int>(0, out var integers) method can be used. However in the case of curves it cannot be known ahead of time what the type constraint of the twig in question may be. If the input contains only Circle values, then it will be a Twig<Circle>, but a curve parameter may contain a mixture of different types, so we ought to revert to the non-generic ITwig approach.
2. Similarly, since we can’t know the type constraints ahead of time, it is not possible to use Pear<T> as a list constraint and we must fall back to the non-generic IPear. A pear is nothing more than the pairing of a value with its meta data. It is called a “pear” rather than a “pair” because “pair” was already taken and “pear” fits nicely within the tree-paradigm. All data tree types in GH2 are immutable, which means we cannot build a twig or tree over time. Instead, we must aggregate the contents in mutable collection types which are then converted into the appropriate twig/tree all at once.
3. There are several ways to iterate over the contents of a twig, but if the indices of values are not required, there are several handy enumerators which allow foreach to do all the heavy lifting.
4. The only reason this component needs cancellation support is because the twigs it operates on may contain thousands if not millions of values.
5. We need to find the curve assistant for each curve-like value in the twig. The TypeAssistantServer is a static class which maintains all registered assistants and provides easy lookup based on values or types. The curve assistant allows us to query the start and end-points of the curve value, even if we don’t know the type of that value. It could be a Rhino.Geometry.Line, or a Rhino.Geometry.NurbsCurve, or even a curve type which is shipped as part of a 3rd party plugin years after the code for this component was written.
6. This part seems self-explanatory.
7. Once all pear lists have been made they can be converted into twigs and assigned to each output. The Garden static class provides a large number of utility functions for creating and modifying pears, twigs and trees.

Validation and Messaging

Components in GH2 have the ability, just as they did in GH1, to collate warning and error messages during processing. In general, warnings ought to be used when there was a problem the component could work around, and errors ought to be used when the component could not complete its calculations. However, unlike in GH1, the IDataAccess argument provides a set of validation and rectification methods which automatically set warning and error messages, if need be. This tends to simplify the portion of the processing code which deals with input validation.

Next time you need to make sure numbers are positive, or fall within a given range, or that two vectors aren’t parallel, or three points aren’t collinear, have a look at all the methods starting with Rectify___ and Verify___ on IDataAccess.

When a custom warning or error needs to be signalled to the user, the access argument also provides direct ways of adding runtime messages to the component. The IDataAccess.AddWarning() and IDataAccess.AddError() methods allow the developer to set runtime messages with custom phrasing and custom actions. Adding message actions which allow the user to fix problems is strongly encouraged whenever possible. When messages have actions, they will appear in the message menu as follows:

Custom Properties

In GH1, any component which needed to remember a custom setting (a mode picked from the context menu, a toggle state, …) had to override the Write(GH_IWriter) and Read(GH_IReader) methods and handle the serialisation of that setting by hand. GH2 still allows this (see below), but for settings using primitive types there is now an easier to use mechanism which requires no serialisation code at all.

Every document object carries a CustomValues property of type KeyedValues; a mutable collection of named values which is automatically included whenever the object is written to or read from a file. Storing a setting takes a single Set() call and retrieving it takes a single Get() call, where the second argument acts as the fallback in case the key has not (yet) been assigned:

Because every getter takes a fallback value, there is no need to check whether a key exists before reading it, and components loaded from files which predate the introduction of a setting will just get the fallback. Key comparisons are case-insensitive, and access is thread-safe.

The natively supported types are bool, int, double, string, Guid, DateTime, TimeSpan, and the Eto.Drawing primitives (Color, Point, PointF, Size, SizeF, Rectangle, RectangleF).

Two caveats. First, assigning a custom value does not expire the solution or the display; if the setting affects computed results, it is up to you to expire the object. Second, changes to custom values are not automatically undoable. When a change ought to appear on the undo stack, you must create an undo snapshot of the values before modifying them using a CustomValueAction, then commit that action afterwards:

Overriding Store() and the Reader Constructor

When object state does not fit into the CustomValues collection (collections, nested data structures, other complex types) the GH1 approach is still available. The Store(IWriter) method is the equivalent of Write(), and deserialisation happens in the constructor which takes an IReader, the very same constructor every document object is already required to have:

Note that the Store() override must always invoke base.Store(writer), and the reader constructor must always invoke : base(reader). Forgetting either will lead to broken file IO.

This approach is discouraged for simple settings because it shifts all versioning responsibility onto the developer. Every name and type you ever write into a file becomes a contract with every file saved from that day forward, and reading code must forever guard against items which are absent from older files (note the HasItem() check above). The CustomValues mechanism handles all of that for you; reserve Store() overrides for state which genuinely cannot be expressed any other way.

Variable Parameter Layouts

As in GH1, components in GH2 can have variable numbers of inputs and outputs. All that is needed to enable the user interface for adding or removing inputs and outputs is to override the CanCreateParameter(), DoCreateParameter() and CanRemoveParameter() methods. The DoRemoveParameter() may be overridden as well, but the default behaviour already does what it says on the tin. Lastly, the VariableParameterMaintenance() method is still the best place to ensure that all properties of all parameters are correctly set.

Let’s explore this with a component which creates bounding boxes for points in a variable number of inputs. Since we are creating a component which has a fully functional VariableParameterMaintenance() implementation, we can avoid assigning names and requirements inside the AddInputs() method:

Now the three required overrides, with an absolutely minimal implementation:

Lastly the implementation of the maintenance method, which does all the heavy lifting:

Note that this code assigns the FallbackName of each parameter rather than the UserName. This prevents us from overwriting user typed names on inputs. The DisplayName of a parameter is either the UserName or the FallbackName, depending on which one has been set.

Iterating over a variable number of parameters is quite easy by using the IDataAccess.CountIn and IDataAccess.CountOut properties. Since the inputs have a requirement of MayBeMissing, we need to check to see whether the IDataAccess.GetItem() method returns true or false. An input with a null value or with no values at all will return false when queried.

Modular Components

Whereas variable parameters are typically used for adding inputs or outputs that are all the same kind of thing, and for which there is no upper limit, Grasshopper 2 adds the notion of a ‘Modular Component’ which is capable of hiding and showing specific inputs and outputs. When a component class is derived not from Grasshopper2.Components.Component but from Grasshopper2.Components.ModularComponent, the AddInputs() and AddOutputs() methods are replaced with their modular counterparts.

Creating modular components is quite a bit more involved as modular inputs and outputs need to be grouped into categories, given UI tinting, and often even icons. This document will only mention this corner of the Grasshopper 2 SDK without providing any examples.

Data Types

Data Trees

Structured data in GH2 is still organised in trees, and any GH1 developer will recognise the overall shape immediately: a tree is a collection of twigs, each one uniquely identified by a path of integers, and each twig contains an ordered list of items. What has changed is the naming, the type constraints, meta data support, and above all the mutability.

The types involved, from large to small:

Type	Role
Tree<T> / ITree	The whole data structure; the equivalent of GH_Structure<T>.
Paths	The sorted collection of paths in a tree.
Path	An ordered, immutable list of non-negative integers identifying a twig; the equivalent of GH_Path.
Twig<T> / ITwig	An immutable list worth of items and their associated meta data; the equivalent of List<GH_Goo<T>> in GH1.
Pear<T> / IPear	A single value paired with its meta data.
Site	The location (path plus index) of an item within a tree.
MetaData	The immutable collection of named meta values associated with a single item.

Most of these types come in a generic and a non-generic interface flavour. Use Tree<T>, Twig<T>, and Pear<T> whenever the item type is known at compile time, and fall back to ITree, ITwig, and IPear when the data may be of mixed or unknown types.

The salient differences with GH1 are:

• No more goo. GH_Structure<T> demanded that T implemented IGH_Goo; Tree<T> stores plain values.
• Everything is immutable. Trees, twigs, paths, and pears cannot be modified after creation. The GH1 habit of creating an empty structure and appending to it as you go has been replaced by aggregating values in ordinary mutable collections (a List<T>, an array) and converting to a twig or tree in a single step at the end.
• Meta data exists. Every item in a twig may carry meta data, and the pear is the unit which keeps a value and its meta data together. A Twig<int> which contains both meta data and null values will under the hood maintain three separate arrays; int[] for the actual values, bool[] for the null states, and MetaData[] for the meta data.

Twigs and trees are not created via constructors; the actual instances are specialised internal implementations chosen based on content (with or without nulls, with or without meta data, value or reference types). Instead, all creation goes through the static Garden class; the one-stop-shop for growing trees. It contains factory methods for a lot of different tree and twig creation methods: TwigFromList(), TwigFromPears(), TreeFromArrays(), ITreeFromITwigs(), and dozens more, along with utilities for merging trees, casting between generic and non-generic forms, and comparing pears.

Modifying existing trees and twigs is often done with instance methods on ITree, Tree<T>, ITwig or Twig<T> directly, just remember these methods always return new tree and twig instances, as the existing instances are immutable.

Meta Data

Meta data has no GH1 equivalent whatsoever, and it is the reason several familiar operations require more care in GH2. Any value flowing through a Grasshopper document may carry an unbounded collection of named values alongside itself: an element identifier, a comment, a preview colour, a target layer for baking, a material density, …. Users can attach and inspect these values without any component being aware of them, and well-behaved components must make sure the meta data survives the trip through their processing logic. As explained in the Data Trees chapter, the pear is the mechanism for this: as long as data is shuffled around as pears, the meta data tags along automatically.

The design rests on a few assumptions: most items carry no meta data at all, identical meta data is typically shared among many items, and meta data is read far more often than it is written. As a consequence MetaData is fully immutable — a single instance can be safely shared among thousands of items, and “modifying” meta data (via Add() or Merge()) always yields a new instance. The values themselves are limited to immutable types: booleans, integers, big integers, numbers, angles, intervals, text, guids, dates, time spans, colours, gradients, points, vectors, planes, transforms, and a few others.

Entries are identified by MetaName instances rather than plain strings. A meta name is an immutable, case-insensitive list of name elements which are joined using the . separator, so they form textual hierarchies such as Record.Author and Display.Colour.

The names Grasshopper itself uses are collected in the static StandardNames class, grouped into nested classes per topic: Record (author, comment, client, version), Display (preview colour, stroke, dashes, point size), Rhino (layer, name, colour, linetype, and other attributes applied when data is baked), Data, Annotation, and Physics.

A complication developers need to be aware of:

• Transformable entries. A meta name may carry a transformable hint, denoted by a trailing # in its textual form. When geometry is transformed or morphed, the geometric values (points, vectors, planes, transforms) stored under transformable names are transformed along with it, whereas entries under ordinary names are copied verbatim. Think of a gripping location on a beam: when the beam moves, the grip should move too. The IDataAccess method used in component Process() methods provides functions for transforming shapes along with their meta data.

Type Handling

In GH1, every value was wrapped in an IGH_Goo container, and that container was responsible for everything the value could do: formatting, duplication, validity, previews, baking, transformations, and casting to and from other types. GH2 takes a dramatically different tack. Values in GH2 are stored as-is (a circle in a data tree really is a Rhino.Geometry.Circle) and all shared functionality is provided by separate objects which are registered centrally. The many features which IGH_Goo used to provide are now handled by two separate systems; assistants provide type functionality, and the conversion server provides data conversion between types.

Both systems share the same registration model: when a plugin loads, its assembly is scanned and all assistant and conversion repository classes are instantiated and registered automatically. There is no manual registration step; the classes merely have to be public and have parameterless constructors.

This chapter only explains the design from the perspective of a component developer consuming existing types. Creating your own data types — and the assistants, conversions, and parameters that come with them — is a big enough topic to deserve a document of its own.

Type Assistants

Every type which flows through Grasshopper 2 should be associated with an ITypeAssistant, and the static TypeAssistantServer class maintains the registry and provides lookup by type or by value. The assistant answers on behalf of the type whenever Grasshopper has a question: “What is your name?”, “Are you valid?”, “How do I create a duplicate?”, “How are you drawn in the Rhino viewports?”, “Do you have a bounding box, and if ‘yes’ how big is it?”, …

Not every type supports every operation (a colour cannot be drawn in viewports, a mesh has no length) so each capability is advertised through a property with a Zupports prefix: ZupportsDraw, ZupportsBake, ZupportsLength, ZupportsClosestPoint, and so on. Whenever a type assistant overrides a virtual method, the base class detects this and sets the appropriate ZupportsXyz property to true. Code which consumes an unfamiliar assistant ought to check the relevant Zupports property before relying on the matching operation.

Curve-like and surface-like types get an additional, more specialised treatment. Whereas the GH1 Curve parameter converted every incoming value to a Rhino.Geometry.Curve, the GH2 parameter stores values untouched and requires only that each curve-like type registers an ICurveAssistant (in practice by deriving from the CurveAssistant base class; never implement the interface from scratch). The assistant answers all curve questions — domains, spans, end points, conversion to NURBS or polyline form — so a component which operates on curves through assistants automatically works with every registered curve type, including types shipped by other plugins years after the component was written. Surface-like types follow the same pattern via ISurfaceAssistant and the SurfaceAssistant base class.

Component developers who do not care about any of this and simply want a Rhino curve or brep out of whatever value they were handed can use the static CurveBroker and SurfaceBroker utility classes, which perform the type-checking and conversion song-and-dance in a single call.

Type Conversion

The CastTo/CastFrom logic which used to live inside each IGH_Goo type is replaced by the static ConversionServer, a central registry of conversion delegates keyed by (source type, target type) pairs. Plugins contribute conversions by deriving a class from ConversionRepository and filling it with public static methods which take a source value and produce a target value via an out parameter.

Every conversion method must be decorated with a Merit attribute, which expresses how sensible the conversion is: Direct, Fair, Plausible, Strange, or Weird. When data of one type arrives at a parameter of another, the server picks the best available conversion, and the merit travels along with the result. Low-merit conversions are deliberately surfaced to users as a hint that, although Grasshopper managed to perform the requested conversion, they may well be doing something wrong.

The complete set of registered conversions can be inspected from within Grasshopper via the Conversion Graph entry in the Solver menu, which displays all conversion pairs known to the server as a chord diagram.

Renaming Cheat-Sheet

The table below maps the GH1 types, members, and concepts you’re likely to search for onto their GH2 counterparts. It is organised roughly by topic: plugin level first, then components and parameters, data access, data structures, document objects, user interface, and finally (de)serialisation.

GH1 name	GH2 name	Salient differences
*.gha file	*.rhp file	A single .rhp can be both a Rhino plugin and a Grasshopper plugin.
GH_AssemblyInfo	Grasshopper2.Framework.Plugin	Identity and authorship now come from assembly attributes; see the Plugin Assembly section.
GH_Component	Grasshopper2.Components.Component	Requires an additional deserialisation constructor taking an IReader.
ComponentGuid property	[IoId] class attribute	Lives in GrasshopperIO.dll. Applies to all storable types, not just components.
GH_Exposure property	Rank and Slot (inside Nomen)	Part of the Nomen passed to the constructor rather than a separate override.
Icon property (Bitmap)	IIcon / AbstractIcon	Vector icons are supported and recommended. The override can be omitted when an embedded resource matches the class name exactly.
NickName	UserName, FallbackName, DisplayName	Split in two: FallbackName is set by code, UserName by the user. DisplayName picks whichever is appropriate.
Name, description, category, subcategory	Nomen	One immutable type bundling name, info, tab, panel, slot, and rank.
RegisterInputParams(GH_InputParamManager)	AddInputs(InputAdder)	Defaults are assigned via Set() on the returned parameter rather than an argument.
RegisterOutputParams(GH_OutputParamManager)	AddOutputs(OutputAdder)
GH_ParamAccess.item/list/tree	Access.Item/Twig/Tree	Item access is the default and need not be specified.
Optional property	Requirement property	Three states instead of a boolean: MustExist, MayBeNull, MayBeMissing.
GH_PersistentParam<T>.PersistentData	Parameter<T>.Set(...)	Overloads exist for single items, collections, and entire trees.
IGH_Param	Grasshopper2.Parameters.Parameter / IParameter	Type-specific functionality lives in Parameter<T>.
IGH_VariableParameterComponent	virtual methods on Component	No separate interface; override CanCreateParameter(), DoCreateParameter(), CanRemoveParameter(), and VariableParameterMaintenance().
Params property	Parameters property	E.g. Parameters.InputCount and Parameters.Input(i).
SolveInstance(IGH_DataAccess)	Process(IDataAccess)	Runs multi-threaded by default; must be thread-safe or downgrade Component.Threading.
GH_TaskCapableComponent	—	Gone. The solver is inherently multi-threaded and cancellable.
DA.GetData(...) / SetData(...)	access.GetItem(...) / SetItem(...)	Uses out instead of ref. Returns false for missing or null data.
-	access.GetPear(...) / SetPear(...)	New. Getting and setting values with meta data requires pears.
DA.GetDataList(...) / SetDataList(...)	access.GetTwig<T>(...) / SetTwig(...)	Use GetITwig(...) when the value types cannot be known ahead of time.
DA.GetDataTree(...) / SetDataTree(...)	access.GetTree<T>(...) / SetTree(...)	Likewise GetITree(...) for mixed or unknown types.
AddRuntimeMessage(GH_RuntimeMessageLevel, ...)	access.AddWarning / access.AddError(...)	Messages take a text and details, and optionally actions which let the user fix the problem. Also see the VerifyXyz and RectifyXyz methods.
GH_Structure<T>	Grasshopper2.Data.Tree<T>	Immutable. Aggregate values in mutable collections and construct trees at the end, typically via Garden.
branch or List<T>	Twig<T> / ITwig	Immutable, and items are paired with meta data (see pears).
GH_Path	Grasshopper2.Data.Path
IGH_Goo / GH_Goo<T>	—	Gone. Values are stored as-is; shared functionality is provided by type assistants, conversions by the conversion server.
GH_ObjectWrapper	-	Gone. Values are stored as-is and do not need to be wrapped.
GH_Convert / CastTo / CastFrom	ConversionServer / ConversionRepository	Conversions are registered centrally instead of being implemented per data type.
GH_Document	Grasshopper2.Doc.Document
GH_DocumentObject	Grasshopper2.Doc.DocumentObject
GH_ActiveObject	Grasshopper2.Doc.ActiveObject
OnPingDocument()	Document property
ExpireSolution(true)	Expire() + Document?.Solution.Start() or Document?.Solution.DelayedExpire(this)	Expiry and recomputation are separate steps. Expiring also request-cancels any running solution in the document.
Locked	Activity property	An ObjectActivity enumeration instead of a boolean.
Hidden	Display property	An ObjectDisplay enumeration instead of a boolean.
RecordUndoEvent(...)	AddUndoRecord(...)	Takes a VerbNoun plus any number of Undo.Action instances.
DrawViewportWires/Meshes(...)	PopulateDisplay(...)	Display geometry is cached centrally rather than drawn per frame.
ClippingBox	DisplayBounds()
AppendAdditionalMenuItems(...)	AppendToInputPanel(...)	Context menus are replaced by the input panel, built from Grasshopper2.UI.InputPanel parts.
IGH_Attributes / GH_ComponentAttributes	IAttributes / Attributes<T>	All custom UI is drawn with Eto rather than WinForms/GDI+, and must work on both Windows and Mac.
GH_Canvas	Grasshopper2.UI.Canvas.Canvas	An Eto control rather than a WinForms one.
GH_IO.dll	GrasshopperIO.dll
GH_IWriter / GH_IReader	IWriter / IReader
Write(GH_IWriter) / Read(GH_IReader)	Store(IWriter) / constructor taking IReader	Deserialisation happens in a constructor so that immutable types can be restored. Prefer CustomValues for simple settings.
GH_Archive	GrasshopperIO.IO	Static methods for reading and writing storable objects to streams, files, and byte arrays.

Edit this page

Edit on GitHub

History

Admin
